----------Enable Mac Address Filter---------
ssid1: dis ssid2: dis ssid3: dis ssid4: dis
----------MAC Address Filter----------
Index Attribute MAC Address Associated SSIDs
0 00:50:70:ff:12:70 ssid1 ssid2 ssid3 ssid4
1 s 00:50:70:ff:12:70 ssid1 ssid2
s: Isolate the station from LAN
>
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
w
w
l
l
c
c
o
o
n
n
f
f
i
i
g
g
This command allows users to configure general settings and security settings for wireless
connection.
wl config mode [value]
wl config mode show
wl config channel [number]
wl config preamble [enable]
wl config txburst [enable]
wl config ssid [ssid_num enable ssid_name [hidden_ssid]]
wl config security [SSID_NUMBER] [mode]
wl config ratectl [ssid_num enable upload download ]
wl config isolate [ssid_num lan member]
wl config dtim [value]
wl config dtim show
wl config beaconperiod
wl config radio enable
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
mode[value]
It means to select connection mode for wireless connection.
Available settings are: "11bgn", "11gn", "11n", "11bg",
"11g", or "11b".
mode show
It means to display what the current wireless mode is.
channel [number]
It means the channel of frequency of the wireless LAN.
The available settings are 0,1,2,3,4,5,6,7,8,9,10,11,12 and 13.
number=0, means Auto
number=1, means Channel 1
….
number=13, means Channel 13.
preamble [enable]
It means to define the length of the sync field in an 802.11
packet.
Most modern wireless network uses short preamble with 56
bit sync field instead of long preamble with 128 bit sync
