Draytek Vigor2120 Series User Manual

Vigor2120 Series User’s Guide
446
list
It can display current setting for your reference.
add
It means adding a new entry.
index
It means to specify the number of the entry.
ip addr
It means to specify an IP address.
mask
It means to specify the subnet mask for the IP address.
remove
It means to delete the selected item.
flush
It means to remove all the settings in the access list.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> mngt accesslist add 1 192.168.1.89 255.255.255.0
%% Set OK.
> mngt accesslist list
%% Access list :
Index IP address Subnet mask
==========================================
1 192.168.1.89 255.255.255.0
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
m
m
n
n
g
g
t
t
s
s
n
n
m
m
p
p
This command allows you to configure SNMP for management.
mngt snmp [-<command> <parameter> | ... ]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
[<command>
<parameter>|…]
The available commands with parameters are listed below.
[…] means that you can type in several commands in one
line.
-e <1/2>
1: Enable the SNMP function.
2: Disable the SNMP function.
-g<Community name>
It means to set the name for getting community by typing a
proper character. (max. 23 characters)
-s <Community name>
It means to set community by typing a proper name. (max. 23
characters)
-m <IP address>
It means to set one host as the manager to execute SNMP
function. Please type in IPv4 address to specify certain host.
-t <Community name>
It means to set trap community by typing a proper name.
(max. 23 characters)
-n <IP address>
It means to set the IPv4 address of the host that will receive
the trap community.
-T <seconds>
It means to set the trap timeout <0~999>.
-V
It means to list SNMP setting.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
