Vigor2120 Series User’s Guide
469
T
T
e
e
l
l
n
n
e
e
t
t
C
C
o
o
m
m
m
m
a
a
n
n
d
d
:
:
q
q
o
o
s
s
c
c
l
l
a
a
s
s
s
s
This command allows user to set QoS class.
qos class -c [no] –[a|e|d] [no][-<command> <parameter> | ... ]
S
S
y
y
n
n
t
t
a
a
x
x
D
D
e
e
s
s
c
c
r
r
i
i
p
p
t
t
i
i
o
o
n
n
Parameter Description
[<command>
<parameter>|…]
The available commands with parameters are listed below.
[…] means that you can type in several commands in one
line.
-h
Type it to display the usage of this command.
-c <no>
Specify the inde number for the class.
Available value for <no> contains 1, 2 and 3. The default
setting is class 1.
-n <name>
It means to type a name for the class.
-a
It means to add rule for specified class.
-e <no>
It means to edit specified rule.
<no>: type the index number for the rule.
-d <no>
It means to delete specified rule.
<no>: type the index number for the rule.
-m <mode>
It means to enable or disable the specified rule.
0: disable,
1: enable
-l <addr>
Set the local address.
Addr1 – It means Single address. Please specify the IP
address directly, for example, “-l 172.16.3.9”.
addr1:addr2 – It means Range address. Please specify the IP
addresses, for example, “-l 172.16.3.9: 172.16.3.50.”
addr1:subnet – It means the subnet address with start IP
address. Please type the subnet and the IP address, for
example, “-l 172.16.3.9:255.255.0.0”.0
any – It means Any address. Simple type “-l” to specify any
address for this command.
-r <addr>
Set the remote address.
addr1 – It means Single address. Please specify the IP
address directly, for example, “-l 172.16.3.9”.
addr1:addr2 – It means Range address. Please specify the IP
addresses, for example, “-l 172.16.3.9: 172.16.3.50.”
addr1:subnet – It means the subnet address with start IP
address. Please type the subnet and the IP address, for
example, “-l 172.16.3.9:255.255.0.0”.0
any – It means Any address. Simple type “-l” to specify any
address for this command.
-p <DSCP id>
Specify the ID.
