Vigor2120 Series User’s Guide
277
Available settings are explained as follows:
Item Description
Set to Factory Default
Click to clear all indexes.
Name
Indicate the name of the LAN-to-LAN profile. The
symbol ??? represents that the profile is empty.
Active
V – means the profile has been enabled.
X – means the profile has not been enabled.
Status
Online – means such LAN to LAN profile is in use.
Offline – means such LAN to LAN profile isn’t in use even
if the profile has been enabled.
To edit each profile:
1. Click each index to edit each profile and you will get the following page. Each
LAN-to-LAN profile includes 4 subgroups. If the fields gray out, it means you may leave
it untouched. The following explanations will guide you to fill all the necessary fields.
For the web page is too long, we divide the page into several sections for explanation.
