Vigor2120 Series User’s Guide
326
Item Description
 Must -Specify the IPSec policy to be definitely applied
on the L2TP connection.
Must - It allows the remote dial-in user to make an SSL VPN
Tunnel connection through Internet, suitable for the application
through network accessing (e.g., PPTP/L2TP/IPSec)
If you check this box, the function of SSL Tunnel for this
account will be activated immediately.
Specify Remote Node - Check the checkbox to specify the IP
address of the remote dial-in user, ISDN number or peer ID
(used in IKE aggressive mode). If you uncheck the checkbox,
the connection type you select above will apply the
authentication methods and security methods in the general
settings.
Netbios Naming Packet
 Pass – Click it to have an inquiry for data transmission
between the hosts located on both sides of VPN Tunnel
while connecting.
 Block – When there is conflict occurred between the
hosts on both sides of VPN Tunnel in connecting, such
function can block data transmission of Netbios Naming
Packet inside the tunnel.
Multicast via VPN - Some programs might send multicast
packets via VPN connection.
 Pass – Click this button to let multicast packets pass
through the router.
 Block – This is default setting. Click this button to let
multicast packets be blocked by the router.
Subnet
Chose one of the subnet selections for such VPN profile.
Assign Static IP Address – Please type a static IP address for
the subnet you specified.
SSL VPN
Set SSL Application - Choose the SSL application profile to
be applied by such dial-in user profile.
User Name
This field is applicable when you select PPTP or L2TP with or
without IPSec policy above.
Password
This field is applicable when you select PPTP or L2TP with or
without IPSec policy above.
Enable Mobile
One-Time Passwords
(mOTP)
Check this box to make the authentication with mOTP
function.
PIN Code – Type the code for authentication (e.g, 1234).
Secret – Use the 32 digit-secret number generated by mOTP in
the mobile phone (e.g., e759bb6f0e94c7ab4fe6).
IKE Authentication
Method
This group of fields is applicable for IPSec Tunnels and L2TP
with IPSec Policy when you specify the IP address of the
