Vigor2120 Series User’s Guide
553
wpa2psk [key]: WPA2/PSK
key: Moreover, you have to add keys for wpapsk, wpa2psk,
and wep, and specify index number of schedule profiles to be
followed by the wireless connection.
WEP keys must be in 5/13 ASCII text string or 10/26
Hexadecimal digit format; WPA keys must be in 8~63 ASCII
text string or 64 Hexadecimal digit format.
e.g.,
wl dual wds security disable
wl dual wds security wep 12345
wl dual wds security wpa2psk 12345678
ap [value]
It means to enable or disable the AP function.
Value: 1 – enable the function.
0 – disable the function.
hello [value]
It means to send hello message to remote end (peer).
Value: 1 – enable the function.
0 – disable the function.
status
It means to display WDS link status for 5GHz connection.
show
It means to display current WDS settings.
mac add [index addr]
add [index addr] – Add the peer MAC entry in
Repeater/Bridge WDS MAC table.
mac clear/disable/enable
[index/all]
clear/disable/enable [index/all]- Clear, disable, enable the
specifed or all MAC entries in Repeater/Bridge WDS MAC
table. e.g,
wl dual wds mac enable 1
flush
It means to reset all WDS setting.
E
E
x
x
a
a
m
m
p
p
l
l
e
e
> wl dual wds status
Please enable WDS hello function first.
> wl dual wds hello 1
% <Note> Please restart router after you set the parameters.
> wl dual wds mode b
> wl dual wds security wep
>
>
> wl dual wds show
5G Wireless WDS Setting
Mode : Bridge
Security : WEP
AP Function : Enable
Send Hello Function : Enable
Bridge :
