25
Example, Option Enabled ‘01’
Printer:
Computer:
Computer message combining for DVACS SIA protocol
Computer message combining When DVACS extended option enabled
NOTE:This will support 0-F group numbers maximum.
[069] TL300 Contact ID Kiss-off Duration
Default: 08
Some control panels may require a different kiss-off duration than the default of 800ms. Pro-
gram this option for the duration of the Contact ID kiss off provided to the panel. Each unit has
increments of 100 ms in hex, from 100 ms to a maximum of 8.1 seconds.
For example: 08 = 800 ms
0A = 1000 ms (1 second)
NOTE:Kiss-off durations greater than 1.5 seconds may not be compatible with some alarm
panel. This may be required for special applications. Kiss-off durations higher than 8.1 sec-
onds will not be accurate and may not match the duration programmed.
[070] TL300 Contact ID Handshake Selection
Default: 2D
1400Hz or Dual tone Handshake can be selected.
Enter “2D” for Dual Tone or Enter “14” for 1400Hz
[071] TL300 Dialtone Selection
Default: 00
Enter the 2-digit code corresponding to country indicated in the table below.
[901] Current T-Link IP Address
The Current T-Link IP Address is a read-only option. If this option is selected through the panel
programming, the T-Link module will respond with the current IP address of the T-Link and
display it on the keypad for the user.
01 Nov 2004-11:38:22-01/02-SG -01-1-001--012- Grp 1 Arming!B4
01 Nov 2004-11:38:22-01/02-SG -01-1-001--012- Grp 2 Arming!B5
01 Nov 2004-11:38:22-01/02-SG -01-1-001--012- Close User# 01
1011sssssss012sC1s01
1011sssssss012sC2s01
3RRLssssss0AAAOGs002 (partition(OG/CG)
3RRLssssss0AAAOPs001 (user number)
SRRL[#AAAA|Nri2/OP001][14]
Code Country Code Country
00
01
02
03
04
05
06
07
United States/ Canada
The Netherlands
United Kingdom
South Korea
Taiwan
Italy
Brazil
Germany
08
09
0A
0B
0C
0D
0E
0F
Norway
Sweden
Switzerland
Australia
France
Belgium
Future Use
Future Use
