DSC WP8030 User Manual

INTRODUCTION
6 D-306232 WP8010/WP8030 V18 DSC EN USER
No.
Indication
Function
Arm (Red): Lights when the system is in the armed state.
Chime (Green): Chime zones will chime when disturbed (see Chapter 2).
Trouble (Orange): Lights when the system is in a state of trouble (see Chapter 5).
Control Keys
No.
Indication
Function
NEXT: Advance from item to item within a given menu.
BACK: Move one step back within a given menu.
OK: Review status messages one by one and also select a displayed option.
Arming Keys
No.
Indication
Function
AWAY: Arming when nobody is at home
HOME: Arming when people remain at home.
INSTANT: Canceling the entry delay upon arming (AWAY or HOME)
DISARM / OFF: Disarming the system and stopping alarms
PARTITION: Partition selection
Other Keys
No.
Indication
Function
Chime ON/OFF
Reviewing the event log
Emergency (hold for 2 sec.)
Fire (hold for 2 sec.)
+
Press both buttons simultaneously for panic alarm
PGM control
PGM output OFF
PGM output ON
Volume up *
Volume down *
Record message *
Play message *
Mute speaker * / **
* May not be functional on all versions of WP Panel.
** The Mute Speaker button is active only if the "Set Voice Option" function is enabled (see Chapter 6, section B.14).
1
1
Refers to WP8030 with voice option only
3
4
5
7
8
9
12
10
14
11
16
13
15
17
18
19
20
21
22
23
24
25
26
27
