DSE Model 4110 AutoStart Operators Manual
057-022 4110 OPERATING MANUAL ISSUE 5.1 18/06/2007 JR 15
8 INSTALLATION INSTRUCTIONS
The model DSE 4110 Module has been designed for front panel mounting. Fixing is by 2 clips for easy assembly.
8.1 PANEL CUT-OUT
154 mm
(6.1”)
FIG 3
Maximum panel thickness – 8mm (0.3”)
In conditions of excessive vibration the module should be mounted on suitable anti-vibration mountings.
98 mm
(3.9”)
