DSE DSE9130 - Page 2

ADVANCED FEATURES
 
•
Constant current- maximum
current available during charge
recovery phase
• Constant voltage
• Chargers automatically return to
float mode when charging is
complete

• Makes the chargers ideal for all
battery types
 
• Reverse polarity protection,
short circuit protection and
current limiting
• Automatic recovery after the
removal of fault conditions

• Boosts and equalises cell
charge improving battery
performance and life
• Simple boost connection using
on-board terminals
  
• Once the battery is fully
charged the chargers switch to
Eco-Power to save energy
KEY BENEFITS
• Suitable for a wide range of
battery types
• No moving parts for longer
battery charger life
• Switched mode design
• Charge fail output
• Minimum 80% efficiency
throughout full operating range
  
• Multiple modules can be linked
together to provide larger current
output
DSE9150 - 3 A 12 V
DSE9130 - 5 A 12 V
DSE9155 - 2 A 30 V
DSE9255 - 5 A 24 V
DEEP SEA ELECTRONICS PLC UK
Highfield House, Hunmanby Industrial Estate, Hunmanby YO14 0PH
TELEPHONE +44 (0) 1723 890099 FACSIMILE +44 (0) 1723 893303
EMAIL sales@deepseaplc.com WEBSITE www.deepseaplc.com
DEEP SEA ELECTRONICS INC USA
3230 Williams Avenue, Rockford, IL 61101-2668 USA
TELEPHONE +1 (815) 316 8706 FACSIMILE +1 (815) 316 8708
EMAIL sales@deepseausa.com WEBSITE www.deepseausa.com
055-059/10/10 (7)
RELATED MATERIALS
TITLE PART NO’S
DSE9000 Series Installation Instructions 053-049
DSE9000 Series Operator Manual 057-085
D
S
E
9
1
3
0
,
D
S
E9
1
5
0
,
D
S
E9
1
5
5
&
D
S
E9
2
5
5
C
OM
P
A
C
T
B
AT
TE
R
Y
C
H
A
R
GE
R
S
2
A
M
P,
3
A
M
P
&
5
A
M
P
O
P
T
I
O
NS
®
DSE 
F
E
AT
U
R
E
S
Registered in England & Wales No.01319649
VAT No.316923457
Deep Sea Electronics Plc maintains a policy of continuous development and reserves the right to change
the details shown on this data sheet without prior notice. The contents are intended for guidance only.
SPECIFICATION
AC SUPPLY
FREQUENCY RANGE
48 Hz to 64 Hz
DSE9130 & DSE9255 VOLTAGE RANGE
90 V to 305 V (L-N)
DSE9150 VOLTAGE RANGE
90 V to 265 V (L-N)
DSE9155 VOLTAGE RANGE
85 V to 265 V (L-N)
DC OUTPUT
DSE9130 OUTPUT
5 A DC 12 V DC at 13.7 V DC
DSE9150 OUTPUT
3 A DC 12 V DC at 13.7 V DC
DSE9155 OUTPUT
2 A DC 30 V DC at 34.3 V DC
DSE9255 OUTPUT
5 A DC 24 V DC at 27.4 V DV
RIPPLE AND NOISE
<1%
EFFICIENCY
>80%
REGULATION
LINE
<0.001% Vo
LOAD
1% Vo
PROTECTIONS
Short Circuit
Over Voltage
Over Current
Reverse Polarity
DIMENSIONS
DSE9150 DIMENSIONS
108 mm x 101 mm x 49 mm
4.2” x 4” x 1.9”
WEIGHT
0.16 kg
DSE9130, DSE9155 & DSE9255
DIMENSIONS
136 mm x 140 mm x 63 mm
5.4” x 5.5” x 2.5”
WEIGHT
0.5 kg
OPERATING TEMPERATURE RANGE
-30 °C to +55 °C
-22 °F to +122 °F
STORAGE TEMPERATURE RANGE
-40
o
C to +85
o
C
-40 °F to +185 °F
