Specifications
42
3.6.14 DSE9481 (MKII) 12V/24V 5A
NOTE: This battery charger is designed to be mounted with the base to a vertical surface
with the terminal strips at the bottom.
Overall size(mm)
205mm x 135mm x 80mm
(8.0” x 5.3” x 3.1”)
Weight 0.7kg
Mounting type DIN rail or chassis mounting
Din rail type EN 50022 35mm type only
Mounting holes Suitable for M4
Mounting hole centres
190mm x 120mm
(7.5” x 4.7”)
Input voltage (nominal) 110V-277V
Input voltage (absolute range) 95V-305V
Charge failure relay rating
3A DC resistive
30V maximum
Operating Temperature
-30°C to 85°C with de rating
(-22°F to 185°F with de rating)
