Specifications
20
3.5.6 DSE9250 24V 3.7A
NOTE: - This battery charger is now obsolete, details provided for information only.
Output Voltage (24 V DC Battery) 25.0V 27.4V 30.0V Specify float voltage on ordering.
Output Charging Current (A) 0A 3.7A 4A
Current limit threshold (A) 3.6A 3.75A 4A
Recovery from current limit (A) 3.6A
Full load AC input current (A) 2A With output at 27.6V DC
AC Input Inrush (10ms) current (A) 30A
0.8
0.82
0.84
0.86
0.88
0.9
0.92
85 110 230 260
Efficiency (%)
Input Voltage (V)
DSE9250 Efficiency Curve at 3.7A
