Specifications
32
3.6.4 DSE9150 12V 2A
NOTE: This device is no longer available, replaced by DSE9150 12V 3A. See overleaf for
updated specifications.
NOTE: This battery charger is designed to be mounted with the base to a vertical surface
with the terminal strips at the bottom.
Overall size
108.03mm x 101.10mm x 48.6mm
(4.25” x 3.98” x 1.91”)
Weight 0.16kg
Mounting type DIN rail or chassis mounting
Din rail type EN 50022 35mm type only
Mounting holes Suitable for M4
Mounting hole centres
91mm x 89mm
(4.25” x 3.51”)
Dimensions in mm unless stated
