Specifications
37
3.6.9 DSE9255 24V 5A
NOTE: This battery charger is designed to be mounted with the base to a vertical surface
with the terminal strips at the bottom.
Overall size 136.48mm x 140.41mm x 63.40mm
(5.37” x 5.53” x 2.5”)
Weight 0.5kg
Mounting type DIN rail or chassis mounting
Din rail type EN 50022 35mm type only
Mounting holes Suitable for M4
Mounting hole centres 119.36mm x 128.36mm
(4.7” x 5.05”)
Dimensions in mm unless stated
