DSE DSE9130 - 5 Indications; Dse907; Dse908

Operation
52
5 INDICATIONS
DANGER OF DEATH : LIVE PARTS exist within the DSE9000 enclosure. The enclosure
cover must not be removed when connected to an AC supply.
5.1 DSE907
Function
Action
Power indication
Illuminated RED when AC power is connected and the POWER switch is in the
‘1’ position
Charge Ammeter Scaled 0A to 10A to show charge current (Max 5A charge)
5.2 DSE908
Function
Action
Power indication
Illuminated RED when AC power is connected and the POWER switch is in the
ON position
Charge Ammeter Scaled 0A to 15A to show charge current (Max 5A charge)
Charge Ammeter
Power Indication
Power Indication
Charge Ammeter
