Specifications
38
3.6.10 DSE9260 24V 10A
NOTE: This battery charger is designed to be mounted with the base to a vertical surface
with the terminal strips at the bottom.
Overall size
152mm x 188mm x 2.44mm
(6.0” x 7.4”x 2.44”)
Weight 0.85kg
Mounting type DIN rail or chassis mounting
Din rail type EN 50022 35mm type only
Mounting holes Suitable for M4
Mounting hole centres
142mm x 128mm
(5.59” x 5.0”)
Input voltage (nominal) 110V-277V
Input voltage (absolute range) 90V-305V
Charge failure relay rating
3A DC resistive
30V maximum
Operating Temperature
-30°C to 55°C
(-22°F to 131°F)
Dimensions in mm unless stated
6 in
2.44 in
7.4 in
