DSE DSE9130 - Dse9470 Mkii, Dse9472 Mkii, Dse9480 Mkii, Dse9481 Mkii

Installation
51
4.3.3 DSE9470 MKII, DSE9472 MKII, DSE9480 MKII, DSE9481 MKII
NOTE: For obsolete parts 9470-001-00 and 9480-001-00 contact DSE Technical Support for
connection details.
Recommended AC fuse
DSE9470 24V/12V 10A
DSE9480 12V/24V 10A
DSE9481 12V/24V 5A
DSE9472 24V/12V 5A
230V AC Input
3.5A antisurge
3.5A antisurge
1.0A antisurge
2.0A antisurge
110V AC Input
6.3A antisurge
6.3A antisurge
2.5A antisurge
3.5A antisurge
