Front brake lever (fig. 22)
Pull in the lever (1) towards the twistgrip to operate the
front brake. The system is hydraulically operated and you
just need to pull the lever gently.
The brake lever is provided with an adjuster (2) for lever
distance adjustment from twistgrip on handlebar.
Lever distance from twistgrip is set via knob (2) (10 click
positions). Turn clockwise to push lever far from twistgrip,
or counterclockwise to take it closer.
1 2
fig. 22
