Stop light (fig. 73)
To replace the rear stop and parking light bulbs, unscrew
the two screws (1) that secure the cover (2). The cover (2)
has two retaining pins on the inner face that hold the tail
light lens (3) in place. Remove the cover (2) from its seat and
remove the tail light lens (3). The bulb is of the bayonet-type:
press and twist counter-clockwise to remove. Change the
bulb and refit by pressing and turning clockwise until it
locates into its seat with an audible click. Refit any parts
you have removed.
Number plate light (fig. 74)
To expose the number plate light bulb, unscrew the two
retaining screws (4) securing the cover (5). Extract the bulb
and replace.
3
2
5
1
4
fig. 73
3
fig. 74
