Ducati 749S 2005 - Gear Change Pedal; Rear Brake Pedal

E
30
Rear brake pedal (fig. 23)
Push down on the pedal (1) with your foot to operate the
rear brake.
The system is hydraulically operated.
Gear change pedal (fig. 24)
The gear change pedal is at rest when in the central
position N, and automatically returns to the central position.
When in this position, light N (3, fig. 4) on instrument panel
is on.
The pedal can be moved:
down = push down on the pedal to engage 1st gear and to
shift down. The N light will go out.
up = lift the pedal to engage the 2nd gear and then the 3rd,
4th, 5th and 6th gears.
Each time you move the pedal you will engage the next
gear.
1
fig. 23
N
2
3
4
5
6
1
fig. 24
