E
65
Adjusting the throttle cable tension
The throttle twistgrip must always have free play of
1.5-2.0 mm at all positions of the handlebars. If needed,
adjust using the adjusters (1 and 2, fig. 61) located on
the steering tube on the left side of the motorcycle.
The adjuster (1) is for throttle opening, whereas adjuster (2)
is for throttle closing.
Slip off the dust covers of the adjusters and slacken the
locknuts. Work the adjusters as follows: turn clockwise
to increase play, anti-clockwise to decrease play. When
finished, tighten the locknuts and refit the dust covers.
1,5÷2 mm
1,5÷2 mm
➤
➤
fig. 60
2
1
fig. 61
