E
80
Checking engine oil level (fig. 79)
Engine oil level can be checked through the sight glass (1)
on the clutch cover. When checking oil level, the motorcycle
should be upright and the engine cold. Allow a few minutes
for oil to settle to a steady level after stopping the engine.
Oil level should be between the marks next to the sight
glass. Top up oil level with SHELL Advance Ultra 4, if low.
Undo the filler plug (2) and top up to correct level. Refit the
plug.
Important
Engine oil and oil filters must be changed by a
Ducati Dealer or Authorized Workshop at regular
intervals, as specified in the routine maintenance chart
(see Warranty Card).
Oil viscosity
SAE 10W-40
The other viscosity degrees indicated in the table can be
used if the local average temperature is within the limits
specified for that oil viscosity.
1
2
fig. 79
–10
Unigrade
Multigrade
0 10 20 30 40 C
40
20W–40 20W–50
15W–40 15W–50
10W–40
10W–30
10W
20W
20
30
