E
95
Wire colour coding
B Blue
W White
V Violet
Bk Black
Y Yellow
R Red
Lb Light blue
Gr Grey
G Green
Bn Brown
O Orange
P Pink
Notes
The system wiring diagram is at the end of this manual.
Legend of fuse boxes (fig. 83 and fig. 84)
Pos. Users Val.
1A High and low beams 15 A
1B Horn, stop light, starter
contactor, flasher
20 A
1C Key on 7.5 A
1D Instrument panel power supply 3 A
2E Engine control unit 3 A
2F Injection relay 20 A
