Warning displaying
The instrument panel manages a number of
warnings and alarms, aimed at giving useful
information to the rider during use.
Upon key-on, if there are any active warnings, the
instrument panel will display the messages for all
the present warnings or alarms: in a large size (A) for
the first 3 seconds and then in a smaller size (B).
When several warnings or alarms are active, they are
displayed in a sequence, one every 3 seconds.
In the following figures, the warnings are shown on
the in the large version and on the right in the
small version.
Air
22
°C
90
°C
Range km450
Total km2600
rpm X1000
1
2
3
4
5
6
7
10
11
km/h
Gear
N
SPORT
DWC 3 DTC 5 ABS 3 EBC 2
10:34
am
Chrono
Setting menu
A
Fig 166
258
