Charging the
Preparation
We recommend recharging the lithium by
connecting the suitable charger directly to
the positive and negative terminals of the
using the cable with clips.
To gain access to and charge it, remove rider
seat as indicated in chapter "Seat lock".
Press tab (A) of retainer (1) downwards, releasing it
from hook (B) and elastic band (2).
Slide out protective gaiter (3) and loosen terminal
retaining screws (4):
●
negative and ground cables (5);
●
positive and ABS positive cables (6).
Slide out the (7) from top.
Fig 176
Fig 177
267
