Ducati DESERTX - Motorcycle Components and Controls

Main components and
devices
Position on the vehicle
1) Windscreen
2) Coolant check
3) Clutch fluid reservoir
4) USB socket
5) Fork adjusters
6) Front brake fluid reservoir
7) Rear-view mirrors
8) Side stand
9) Rider seat and tool kit
10) Power outlet
11) Seat lock
12) Tank filler plug
13) Rear brake fluid reservoir
14) Engine oil check
15) Steering damper
12 7
4
5
5
1
7
14
15
9
6
3
13
11
8
10
2
Fig 14
48
