Power outlet
The motorcycle is provided with a 12 V power outlet
(1).
To access the power outlet, remove the rider seat
(Seat lock).
Power outlet (1) is located under the rider seat, at the
back and on vehicle RH side.
The maximum current that can be withdrawn from
the power outlets is 6 A.
When the engine is do not leave
accessories connected to the power outlet for a long
period of time as the motorcycle could run
flat
Fig 25
55
