Seat lock
By operating lock with key (1), you can remove the
rider seat in order to gain access to the tool kit,
relays, fuses, charge maintaining
connector, and 12 V charge socket.
Turn the key clockwise by 1/4 of a tun, until the seat
catch disengages with an audible click.
rider seat (2) from the front side and slide it out
by releasing tab (A) from the back fastener (B) on
frame.
Fig 17
Fig 18
