Ducati DESERTX User Manual

Light control
Low / High beam
By means of  (1) it is possible to switch from
low beam to high beam and vice versa:
●
position (A) for high beam
●
position (B) for low beam
For high-beam flasher, press the  (1) in
position (C).
If engine is not   turning the key to on, it
is  possible to switch on the lights or
flash.
If within 60 seconds from the manual switching on of
the low or high beam the engine is not  the
lights are turned 
To preserve the motorcycle  the headlight is
automatically switched  when  the engine
and it is then switched on again when the engine has

DRL in "Auto" mode – only for version with
DRL
If DRL have been set in "Auto" mode (see page 212),
the instrument panel automatically manages the
DRL based on the detected ambient light:
C
1
2
1
B
C
A
B
Fig 38
70

Ducati DESERTX Specifications

General

Displacement	937 cc
Power	110 hp (81 kW) @ 9, 250 rpm
Torque	92 Nm (68 lb-ft) @ 6, 500 rpm
Transmission	6-speed
Fuel Tank Capacity	21 liters (5.5 gallons)
Seat Height	875 mm (34.4 inches)
Front Tire	90/90-21
Rear Tire	150/70 R18
Frame	Tubular steel trellis frame
Engine Type	L-Twin, Desmodromic distribution, liquid-cooled
Front Suspension	46 mm upside-down fork
Rear Suspension	Fully adjustable monoshock
Front Brake	2 x 320 mm semi-floating discs, radially mounted Brembo 4-piston calipers
Rear Brake	265 mm disc, Brembo 2-piston floating caliper
Wheels	Spoked wheels
Fuel Injection	Electronic fuel injection
Electronics	Riding Modes, Power Modes, ABS Cornering, Ducati Traction Control (DTC), Ducati Wheelie Control (DWC), Cruise Control
