the
Position (7) inside the special
aiming it in the indicated direction.
Connect the cables, always from the
positive (+) one, as indicated:
1) positive (+) and ABS positive cables (6);
2) negative (-) and ground cables (5).
Tighten terminal screws (4) and position protective
gaiter (3).
Bring elastic band (2) back to its original position by
retainer (1) inside hook (B).
Reposition rider seat as indicated in chapter “Seat
lock”.
The gives explosive gases; never
cause sparks or allow naked flames and
near the When charging the ensure
that the working area is properly ventilated.
Fig 180
Fig 181
