the rider seat
Take special care to the positioning of the rear
fastening tab (A) of seat (2) on the seat (B) present on
frame.
Then position seat (2) in its position and pin (5)
inside seat (D).
Press seat (2) downwards, at pin (5).
Make sure you hear the rear seat click into place
and check that seat is correctly fixed.
Fig 21
Fig 22
52
