Ducati Scrambler Owner's Manual

The main fuse (C) is positioned on the solenoid starter
(D). Remove the fuse cap (E) to reach it. A blown fuse
is identified by the interrupted center link (F).
Important
Switch the ignition key to OFF before replacing
the fuse to avoid possible short-circuits.
Attention
Never use a fuse with a rating other than
specified. Failure to observe this rule may damage
the electric system or even cause fire.
D
E
C
Fig 130
F F
Fig 131
193

Ducati Scrambler Specifications

General

Power	73 hp (54 kW) @ 8, 250 rpm
Transmission	6-speed
Frame	Tubular steel trellis frame
Torque	49 lb-ft (67 Nm) @ 5, 750 rpm
Front Suspension	USD Kayaba 41 mm fork
Rear Suspension	Kayaba rear shock, preload adjustable
Rear Brake	245 mm disc, single-piston caliper
Fuel Tank Capacity	13.5 l (3.6 US gal)
Front Brake	330mm disc, radial 4-piston caliper, ABS
