Duplo DC-6 User Manual

4
Part Names and Their Functions
Appearance (Ejection Side)
No. Name Function
1 Perforation unit
(Optional on 115V
model and 230V Asia
model)
Perforates parallel to the document feed direction.
2 Side guide Receives the processed documents.
3 Back guide Receives the processed documents.
4 USB terminal Used for the connection to your computer on PC Controller using.
5 AC inlet Connect the power cord here.
6 Power switch Press to switch the power on and off.
5
4
3
2
1
6
