Before Programming JOB
The DC-616 can save up to 80 patterns of JOB.
This chapter describes how to program and change a JOB on the control panel of the DC-616.
Before programing a JOB, accurately measure the positions of slits, cuts and creases in mm/inch.
Familiarize yourself with the following instructions to make the programming process easy and
trouble free.
Slitter : There are a total of six slitters. Two sitters are for the margins and the remaining for
siltters are the center of a document.
Cutter : There is a guillotine cutter that performs cuts perpendicular to the document feed
direction. The DC-616 can cut up to 25 cuts on one document.
Creaser: There is a creaser that performs creases perpendicular to the document feed direction.
The DC-616 can crease up to 20 positions on one document.
The DC-616 provides two programming modes, Advanced mode and Simple mode.
Select either mode by your preference on the Slitter entry screen of Settings before programming.
Advanced mode:
You can set slit position alternately from side to side in order of unit along the
document feed direction.
The screen displays Slit1 to Slit6.
Simple mode : You can set slit position in order, from the right side of the document along the
document feed direction.
The screen displays Slit A to Slit F.
