Before Using This Machine
1
Before Using This Machine
Moving range of the slitter
Document feed direction
Slitter 1
Slitter 5
Slitter 3
Slitter 4
Slitter 6
Slitter 2
2
4,6
3,5
1. Moving range of the slitter 1
3.2 to 55.0 mm (0 when it is not specifi ed)
2. Moving range of the slitter 2
Document width - (3.2 to 55.0) mm (0 when it is not specifi ed.)
3. Moving range of the slitter 3
48.0 to (document width-48.0) mm (0 when it is not specifi ed.)
48.0 mm or more distance is required between entered values of the slitter 3
and of the slitter 4.
4. Moving range of the slitter 4
48.0 to (document width-48.0) mm (0 when it is not specifi ed.)
48.0 mm or more distance is required between entered values of the slitter 3
and of the slitter 4.
5. Moving range of the slitter 5
48.0 to (document width-48.0) mm (0 when it is not specifi ed.)
5.0 mm or more distance is required between entered values of the slitter 5
and of the slitter 6.
5.0 mm or more distance is required between entered values of the slitter 3
and of the slitter 5.
6. Moving range of the slitter 6
48.0 to (document width-48.0) mm (0 when it is not specifi ed.)
5.0 mm or more distance is required between entered values of the slitter 5
and of the slitter 6.
5.0 mm or more distance is required between entered values of the slitter 4
and of the slitter 6.
Limitation of the range of each slitter varies by entered values for other slitters.
