Before Using This Machine
1
Before Using This Machine
IMPORTANT
Barcode (Automatic JOB selection)
By adding a barcode which indicates a JOB number on each document, the DC-618 is
automatically set up and starts processing the JOB. You can press the START key and leave.
Even if multiple types of JOBs are loaded on the feed tray at one time, the DC-618 also recognizes
a barcode on documents with the built-in CCD reading. It is automatically set up and fi nishes all the
JOBs.
To use this function, make sure that each document has a barcode printed on it. Refer to the
following procedure for specifi cations and a position of a barcode.
1. Specifi cations
Barcode type: CODE-39
Start/Stop code: Required
Minimum line thickness: 0.254 mm
Thin bar: Thick bar : 1:2.5
Barcode height: 4.0 mm or more
IMPORTANT
CODE-39 barcode must be used.
● When
REG Mark Spec
is set to
Bold
:
Document feed direction: A whole REG mark is required to be within 5.0 to 20.0 mm from the
lead edge of the documnet.
Document width direction: A whole REG mark is required to be within 3.0 to 15.0 mm from the
right edge of the document.
When there are scratches or stains in the printing range of the REG mark, the position
may not be corrected.
Also when the read side of a document is rough and glossy, the CCD may not be able to
read a REG mark or a barcode. (The document may diffusely refl ect light.)
When using specially treated documents (glossy documents), print a bold REG mark on
them in advance. Then, select
Bold
for
REG Mark Spec
.
Document
feed
direction
REG mark
REG mark
position range
20.0 mm
10.0 mm
or more
20.0 mm
10.0 mm or more
3.0 mm
3.0 mm
2.0 mm or more
