Chapter 1 Before Operation

9. Options

DF HAND FEED KIT

[1] [2]

No. Name Function

[1] Handfeedtray Insertion inlet for feeding paper

manually to fold.

[2] Auxiliary feed

guide

Subordinately guides sheets so

that the may be fed properly.
