72
12. STITCHER HEAD
Wire measuring #27 (0.4 mm/0.02 inch) to #25 (0.5 mm/0.02 inch) in diameter can be used. The #25 (0.5 mm/0.02 inch)
provides the best performance.
12-2. Wire
No. Name Function
1
Wire guide spring Feeds wire to the stitching section.
2
Wire guide Guides the wire.
3
Wire feed detection unit Detects wire feed amount and prevents stitching error.
4
Felt disks Cleans the wire surface and applies a small amount of oil.
5
Wire return lock Prevents the wire supplied from returning.
6
Release disk When lowered, releases the wire return lock.
7
Fixing knob Fixes the wire guide spring to the wire tube.
8
Wire tube upper Wire path
9
Stitch length adjustment knob Wire is cut short when rotated clockwise, and long when rotated counterclockwise.
bk
Triangular handle For switching whether to stitch or not
bl
Feed wheels Grip the wire when the triangular handle is set to the stitching position. When rotated,
with the adjusting handle, wire is fed.
bm
Wire tube lower Wire path
bn
Mounting bolt Secures the stitcher head to the mounting block.
bo
Balance adjustment wheel When rotated, adjusts the left and right leg length of a stitch.
bp
Wire straightener Straightens the wire.
bq
Leaf spring Holds the former.
br
Former Cuts the wire and bends it into C shape.
bs
Adjusting handle Used when feeding wire by hand. (Accessory)
bt
Tenon block Secures the stitcher head to the mounting block.
To Next Page
