15. SPECIFICATIONS
Model name
Model
Paper size
Paper quality
Maximum processing
speed
Stitching capacity
Folding capacity
Noise
Ratings
Size of machine
Weight
DBM-500
Stitcher folder
Saddle stitching
Length 178 to 508 mm/7.01 to 20.00 inch
Width 120 to 356 mm/4.72 to 14.02 inch
Side and corner stitching
B5 LEF, A4 (LTR) SEF/LEF, B4 SEF, LGL LEF
*
Some sizes cannot be used. For best results, the length of a sheet should not be more than 2.2
times its length.
Saddle stitching and folding
Fine quality paper 64 to 127.9 GSM/17 to 33 lb
Art and coated paper 84.9 to 157 GSM/ 24 to 41 lb
Thickness of one set : within 2.5 mm/0.10 inch for normal paper
within 1.5 mm/0.06 inch for heavy paper
such as 127.9 GSM/23lb
Cover sheet : Below 300 GSM/79 lb
Side and corner stitching
Fine quality 64 to 127.9 GSM/17 to 33 lb
Thickness of one set : within 5.0 mm/0.20 inch for 81.4 GSM/22lb,A4/LTR paper
within 3.0 mm/0.12 inch for normal paper
5000 sets/hour (fine quality paper 178 (L) x 120 (W) mm/7.01 (L) x 4.72 (W) inch within five sheets)
4500 sets/hour (fine quality 81.4 GSM/22 lb within 10 sheets A4 saddle stitching folding A5 finished)
3900 sets/hour (fine quality 81.4 GSM/22 lb within 10 sheets A3 saddle stitching folding A4 finished)
No. of stitches 0 to 2 (Up to 4 possible with options)
Stitch thickness Within 5 mm/0.20 inch (fine quality 81.4 GSM/22 lb 50 sheets equivalent)
Wire Wire diameter #25 to #27
Below 25 sheets (cover x 1 (300 GSM/79 lb) + 24 sheets (81.4 GSM/22 lb) equivalent)
78 dB (Including scale A, peak)
120 V 60 Hz 6.5 A
When not used: 1610 (W) x 770 (D) x 1020 (H) mm (excludes stitcher head)
63.39 (W) x 30.31 (D) x 40.16 (H) inch (excludes stitcher head)
When used: 2230 (W) x 865 (D) x 1300 (H) mm (includes belt stacker)
87.80 (W) x 34.06 (D) x 51.18 (H) inch (includes belt stacker)
412 kg/908 lb
Specifications and external view are subject to change without prior notice.
SEF : Short Edge Feeding. Paper travels with its short edge leading.
LEF : Long Edge Feeding. Paper travels with its long edge leading.
GSM: g /m
2
