24.8.2 Menu item 602 (manual input test)
Caution: Danger of injury!
Exercise utmost caution when making the input test with the machine
running.
In this menu individual input elements can be tested.
–
Select the desired input element with the keys “ ñ”or“ò”.
The current status is indicated in the display:
0 = input inactive
1 = input active
Input Designation
S09 Push button 1
S10 Push button 2
S11 Foot pedal 1
S12 Foot pedal 2
S13 Foot pedal 3
R0 Sewing motor
R1 X-axis
R2 Y-axis
R3 Z-axis
–
Quit the menu item with key “ESC”.
24.8.3 Menu item 603 (automatic input test)
Caution: Danger of injury !
Exercise utmost caution when making the input test with
the machine running.
With this menu item the function of all input elements is checked.
If the status of an input is altered, this input is automatically indicated
in the display.
–
Quit the menu item with key “ESC”.
55
