DURKOPP ADLER DAC basic

Components and functions
Instructions for use DAC basic/classic - DAC eco plus - OP4X00 - 00.0 - 04/2024 15
Fig. 3: DAC classic, back
(1) - Connection for sewing motor
(2) - Connection for synchronizer
(3) - Connection for CAN
(4) - Connection for additional input
(5) - Connection for machine
(6) - Connection for machine ID
(7) - Connection for pedal
(8) - Connection for control panel
(9) - Connection for sewing motor
encoder
②
①
④
③
⑤
⑥
⑦
⑧
⑨
