Control panel
Instructions for use DAC basic/classic - DAC eco plus - OP4X00 - 00.0 - 04/202424
Needle position
after sewing stop
• Adjusts the needle posi-
tion after sewing stop
p. 30
Point position • Activates or deactivates
the Point position func-
tion for more effortless
needle alignment
p. 30
Thread trimmer • Activates or deactivates
the thread trimmer
• The thread trimmer cuts
the thread at the seam
end automatically.
Thread clamp • Activates or deactivates
the thread clamp
• The thread clamp holds
the needle thread firmly
to pull it down while
sewing on.
Backwards • Activates or deactivates
the Backwards function
Screen lock • Activates the screen
lock
p. 31
Light barrier • Activates the (optional)
Light barrier function
• Detects the end of the
material and activates
end bartack and thread
trimmer automatically.
• Activates sewing stop
at segment switch
• To continue with the
seam, the pedal must
be released in pedal
position 0.
Tile Function Reference
