DXV AT200 - Specifications

6767
Grade D28000AS416-XXX
Rated power 120 VAC, 60 Hz
Rated power consumption 1300 W
Power saving type Instant system
Suitable
tap water
pressure
range
Minimum pressure 14.5 psi (0.10 MPa) or more (when water flow is 4.8 GPM (18 L/min) or more)
Maximum pressure 108.83 psi (0.75 MPa) (static water pressure)
Operating temperature range 32°F (0°C) – 104°F (40°C)
Product dimensions 16
3
/
8
'' (415 mm) (W) x 25'' (635 mm) (D) x 21
7
/
8
'' (555 mm) (H)
Product weight Approx. 70.4 lb (32 kg) (Seat unit: Approx. 22 lb (10 kg), Toilet: Approx. 48.4 lb (22 kg)
Power cord Effective length: 3.28 ft (1.0 m) (with earth)
Toilet
Flush Volume
1.32 gal (5 L) for full flush, 0.92 gal (3.5 L) for partial flush,
and 0.92 gal (3.5 L) for urination by male * (Floor drain or refitting)
Water supply method Uses existing water supply line
Control unit
Cleansing
Warm water supply system Inline ceramic heater for continuous warm water
Flow
Rates
Power cleansing Rear cleansing: 0.10 - 0.13 GPM (0.36 - 0.50 L/min) (6 adjustable levels) when the water pressure is 29.02 psi (0.2 MPa)
Mild cleansing Rear cleansing - mild: 0.10 - 0.13 GPM (0.36 - 0.50 L/min) (6 adjustable levels) when the water pressure is 29.02 psi (0.2 MPa)
Front cleansing
0.10 - 0.13 GPM (0.36 - 0.50 L/min) (6 adjustable levels) when the water pressure is 29.02 psi (0.2 MPa)
Water temperature Water temperature: Approx. 90°F (32°C) – 104°F (40°C) (6 User-defined settings)
Heater capacity 1200 W
Safety device Temperature fuse, thermostat, and flow rate sensor
Drying
with
warm air
Air flow Rate 7.1 CFM (0.2 m
3
/min)
Air temperature Range Room temperature: Approx. 104°F (40°C) – 131°F (55°C) (3 User-defined settings)
Heater capacity 230 W
Safety device Temperature fuse
Seat
heating
Surface temperature
When used: Room temperature and in the range of approx. 82°F (28°C) – 98°F (36.5°C) (6 User-defined
settings)
When the advanced power save function is activated: Room temperature and in the range of approx. 81°F (27°C) –
86°F (30°C)
When the one-touch power save (8 hours) is activated: Room temperature
Heater capacity 48 W
Safety device Temperature fuse
Deodorizing
function
Deodorizing method Chemical absorption by deodorizer cartridge
Deodorizing capacity
Power deodorizing: 3.9 CFM (0.11 m
3
/min)
Full power deodorizing: 4.9 CFM (0.14 m
3
/min)
Turbo deodorizing: 6.0 CFM (0.17 m
3
/min)
Remote control
Standard
remote
control
Dimensions 9
1
/
2
'' (238mm) (W) x 1
1
/
8
''(29 mm) (D) x 1
3
/
4
''(45 mm) (H)
Power Source 2 AAA alkaline batteries
Specifications
