dynabook TECRA A50-J Series User Manual

Maintenance Manual (960-946) 4-43
Replacement Procedures
4.30.2 Installing the Camera module
To install the camera module, follow the steps below and refer to Figure 4-
47 to Figure 4-50.
1. Peel off two protection sheets from the LCD cover.
2. Peel off the protection sheet from a new camera module and stick the
new camera module to the LCD cover.
3. Connect the camera FPC to the connector on the camera module.
4. Peel off the separators on the camera FPC and stick the FPC to the
LCD cover in place.
When replacing the LCD cover with a new one:
■ Stick six pieces of CUSHION on the LCD cover in place for models with
LCD module G33C000A4110, G33C000A6110 or G33C000A7110.
■ Stick two pieces of Gasket on the LCD cover in place for models with
LCD module G33C000AM110 or G33C0009U110.
