Maintenance Manual (960-946)
B-1
A
ppendix
B
Board Layout
B.1 System Board (F
MERSY*) Front V
i
ew
Figure B-1 System Board (FMERSY*) layout (front)
T
able
B-1 System Board (FMERSY*) connectors (front)
Number
Name
CN5590
HDMI I/F connector
CN4850
USB T
ype-A I/F co
nnector
J6320
HeadPhone/Mic jack
J6320
CN4850
CN5590
124
126
