DYNACO USA 3 ● Safety regulations
Slimline Series RevB.doc THE SAFEST CHOICE 9
3.4 Ratchet with extension.
Lock the main switch (with a padlock)
Fit the extension piece to the ratchet and
insert the extension piece into the motor
at the correct location. Turn the door to
the open or closed position.
Unlock the main switch.
Figure 3-2:
Ratchet with
extension
piece.
1 and 2: optional pieces
supplied with the door.
After fixing the problem that required manual operation of the door, you must turn
on the main switch again and open the door to re-charge the frequency inverter.
The lever must be in place before activating the door.
1
2
