DYNACO USA 6 ● DYNALOGIX II (DY 4000)

Slimline Series RevB.doc THE SAFEST CHOICE 31

6.2.2 Make the Encoder Connections

1. Insert the wires into the green connector as listed below. (Terminals are ordered left to right.) See

Figure 6-7.

• Shielded = terminal 1

• White = terminal 2

• Black = terminal 3

• Red = terminal 4

• Green = terminal 5

Figure 6-7: Wiring the Green Connector
