6● DYNALOGIX II (DY 4000) DYNACO USA
34 THE SAFEST CHOICE Slimline Series RevB.doc1
6.3 Final Checks and Verification
Finalizing the door includes setting the door’s open and close limits, ensuring that the door works
properly, and connecting the activation accessories.
Note: An electrician should connect the accessories to the terminal block if possible.
Before you begin:
• Verify that the wiring is properly connected and the Control Box has power.
• Confirm that the connections are properly grounded.
• Confirm that the cable connections are positioned in their terminal slots correctly.
(Photo Eyes and Reversing Edge)
6.3.1 Set the Door Limits
The DYNALOGIX II controls and monitors the curtain’s open and closed position. Once you set the
open and closed limits, test the door to ensure that it is working properly.
Caution: Confirm that all electrical connections are properly wired and terminated before power up.
Refer to the wiring diagram that was enclosed with the DYNACO Door.
Caution: Automatic activations should be disconnected prior to setting limits. If connected, the door
may activate and injury or damage may occur.
1. Enter the programming mode.
2. Press and hold both PROGRAM buttons until display changes to Password. After display
changes, release buttons. See Figure 6-10.
To Next Page
