6.1.2 Messages
Table 6-1 describes the messages that the DYNALOGIX II displays.
Table 6-1: DYNOLOGIX II Messages
Message Cause
Ready
###
All required connections are correct
and the door is ready for operation.
The number indicates the cycle
counter. The DYNALOGIX II will not
allow the door to operate unless this
message displays.
Drive Error
A drive error occurred. Check drive
display for error code.
Rev - Edge
Tripped
The reversing edge is staying or was
activated. Check pneumatic switch for
proper operation.
Opening
Expired
The open run time timer expired. This
is usually caused by an obstruction
somewhere that stops the door from
reaching the open limit setting (full
open). To prevent motor burn out,
when the open run timer reaches 0
the DYNALOGIX II shuts down the
motor. Once you have determined the
cause and made corrections, press
the JOG ×/RESET button.
Closed
Expired
The close run time timer expired. This
is usually caused by an obstruction
somewhere that stops the door from
reaching the close limit setting (full
close). To prevent motor burn out,
when the close run timer reaches 0
the DYNALOGIX II shuts down the
motor. Once you have determined the
cause and made corrections, press
the JOG ×/ RESET button.
SET
LIMITS
The limits have not been set. Set
limits (see Secton 6.3.1: Set the Door
Limits for instructions.)
ENCODER
COM_LOSS
Lost encoder feedback. Check if the
encoder is connected and wired
correctly.
