Dynamic CT10 User Manual

7
Standard 25, 2/5 Matrix
Resolution 5mil
Nominal Working Distance 6~30cm
Decode Rate 200 decodes per second
Scan width 30mm=Scanner Window
Decode mode Single-Line Aiming
Scan mode Auto off mode / Manual mode
Print Contrast Minimum 30%
Scan angles Roll 30° Pitch 75° Yaw65°
Cylinder Horizontal Scan Diameter 35mm
Indication Beeper, LED
Radio Range 10m Visual range
POWER
Voltage DC 5V
Laser Safety Accord with national level two laser safety standards
EMC CE & FCC DOC Compliance
standby Current 35mA
Operating current 60mA
USER ENVIRONMENT
Operating Temp. 0 to 50
.
°C / 32 to 122°F
Storage Temp. 0 to 50
.
°C / 32 to 122°F
Operating Humidity 20-85% ( non-condensing )
Storage Humidity 20-85% ( non-condensing )
Drop Specifications Free fall of 1.5m air drop
Accessories Lithium battery, Charger., Data lines
Correct Aiming
Incorrect Aiming
